Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
10
10
• Channel selection
Up to 4 light channels, one HVAC channel and one Alarm/Message channel can be activated here.
o Light channel 1/2/3/4 (Number of sensors = number of light channels).
In this menu, settings can be made for presence operation such as active sensors, sensitivity,
operating mode of the detector, forced control or blocking object, the sending conditions,
the follow-up time as well as various parameters for external push-button inputs.
o HVAC
The heating, ventilation and air-conditioning channel is the interface between the presence
detector and other systems. In contrast to the light channels, the HVAC channel has
adjustable observation windows with which the presence in the room can be monitored. By
using this channel, it is possible, for example, to control the ventilation of a room according
to demand or to switch other HVAC functions on presence/absence.
o Alarm/Message channel
The alarm channel is used to recognise and detect movements in case of absence. For this
purpose, the channel has a separate sensitivity setting and its own enable/disable object
with which monitoring can be started. Like the HVAC channel, the alarm channel also has
adjustable observation windows.
• Temperature (only Glass Presence Detectors, MR16 and 360° L3 TS)
Here the temperature measurement can be activated, and the measured values can be
configured.
• Constant light control (only for SCN-x360Kx.03)
In this menu, all settings for controlling the constant light function are made. The presence
detector can control up to 3 light bands that are divided between the wall, middle and window.
Intelligent proportional master/slave control ensures that the presence detector controls the
entire room to the same brightness and thus compensates for external influences such as
sunlight.
• Logic
Up to 4 logics can be activated here. Each of these logics can be configured with AND/OR/XOR
functions, various output objects, sending conditions, up to two internal inputs and up to four
external inputs.
2.6 Commissioning
After wiring, the allocation of the physical address and the parameterization of every channel follows:
(1) Connect the interface with the bus, e.g., MDT USB Interface
(2) Switch on bus voltage
(3) Press the programming button at the device (red programming LED lights).
With the SCN-P360L2.03, programming mode is activated by holding the supplied magnet
against the reed switch (red programming LED lights up).
(4) Loading of the physical address out of the ETS-Software by using the interface (red LED
goes off as soon as this process was completed successfully)
(5) Loading of the application, with requested parameterization
(6) If the device is enabled, you can test the requested functions (also possible by using the
ETS-Software)
