Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
11
11
3 Communication objects
3.1 Standard settings of the communication objects
The following table shows the standard settings for the communication objects:
Standard settings
No.
Name
Function
Length
C
R
W
T
U
0
Light channel 1 – Output 1
Switching
1 Bit
X
X
X
0
Light channel 1 – Output 1
(Day)
Switching
1 Bit
X
X
X
0
Light channel 1 - Output
Dimming absolute
1 Byte
X
X
X
0
Light channel 1 - Output
Scene
1 Byte
X
X
X
1
Light channel 1 – Output 1
(Night)
Switching
1 Bit
X
X
X
2
Light channel 1 – Output 2
(Additional)
Switching
1 Bit
X
X
X
3
Light channel 1 – Input
External push button short
1 Bit
X
X
4
Light channel 1 – Input
External push button long
1 Bit
X
X
5
Light channel 1 – Input
External motion (Slave)
1 Bit
X
X
6
Light channel 1 – Input
Status of actuator channel
1 Bit
X
X
7
Light channel 1 – Input
Lock motion detection
1 Bit
X
X
8
Light channel 1 – Input
Forced guidance
2 Bit
X
X
8
Light channel 1 – Input
Lock object
1 Bit
X
X
9
Light channel 1 – Input
Lock object ON
1 Bit
X
X
10
Light channel 1 – Status
Automatic mode
1 Bit
X
X
X
10
Light channel 1 – Status
Lock/Manual mode
1 Bit
X
X
X
11
Light channel 1 – Input
Switch dark
1 Bit
X
X
12
Light channel 1 – Input
Teach-in dimming value for ON
1 Byte
X
X
13
Light channel 1 – Input
Follow-up time 10-65000s
2 Byte
X
X
+15
Next light channel
60
HVAC – Output 1
Switching
1 Bit
X
X
X
60
HVAC – Output 1
Dimming absolute
1 Byte
X
X
X
60
HVAC – Output 1
Scene
1 Byte
X
X
X
63
HVAC – Input
External push button short
1 Bit
X
X
64
HVAC – Input
External push button long
1 Bit
X
X
65
HVAC – Input
External motion (Slave)
1 Bit
X
X
66
HVAC – Input
Status of actuator channel
1 Bit
X
X
