4.3.2.2 Basic function: Switch/send values short/long (with 2 Objects)
Single-button function
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Action: Short / Long
keypress
■ OFF
■ ON
■ toggle
■ send value
■ not active
Setting the function for short or
long keypress.
With „Action ...“ → „send value“
Datapoint type ■ 1 Byte DPT 5.005 Decimal factor (0…255)
■ 1 Byte DPT 5.001 Percent value (0…100%)
■ 1 Byte DPT 17.001 Scene Number
Setting the datapoint type to be
sent.
Value
Scene Number
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Table 55: Settings – Single-button function: Switch/Send values short/long
Functional principle
With this basic function, two different values can be sent for the short and long button. The short and long
buttons have different objects, which also makes it possible to send different datapoint types.
■ ON / OFF : If this setting is used, the same value will always be sent if a keypress is detected.
■ Toggle: It will be sent alternately ON or OFF. Alternatively, the inverted value of the value received via
the object “Status for toggle” will be sent.
■ Send value: The value / scene number setting depending of the selected datapoint type will be sent.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
131 Button left short –
Switch, send value, ...
1 Bit
1 Byte
Sending the value for the short button.
DPT depending on the parameter setting.
132 Button left short –
Status for toggle
1 Bit Receive the status for the short button.
Only with the “toggle” function.
133 Button left long –
Switch, send value, ...
1 Bit
1 Byte
Sending the value for the long button.
DPT depending on the parameter setting.
134 Button left long –
Status for toggle
1 Bit Receive the status for the long button.
Only with the “toggle” function.
+5 Button right ...
Table 56: Communication objects – Single-button function: Switch/Send values short/long
