Je bekijkt pagina 47 van 67
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
47 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.3.2.1.2 Sub function: Toggle when button is pressed
Single-button function
With this function, the button sends the inverted value in relation to the last received status value.
For this purpose, the status object “Status for toggle” is connected to the status of the actuator to be
controlled. If a “ON” signal was received as the last value, the button sends a “OFF” command to the
“Toggle” object the next time it is pressed.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
131 Button left – Toggle 1 Bit Switch function of the button.
132 Button left – Status for toggle 1 Bit Receiving the switching status of the actuator.
+5 Button right ...
Table 52: Communication objects – Single-button function: Toggle
4.3.2.1.3 Sub function: Send value when button is pressed
Single-button function
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Datapoint type ■ 1 Byte DPT 5.005 Decimal factor (0...255)
■ 1 Byte DPT 5.001 Percent value (0...100%)
■ 1 Byte DPT 17.001 Scene number
Setting the datapoint type to be
sent.
Value
Scene number
any value
according to set datapoint type.
Setting the value/scene number
to be sent.
Table 53: Settings – Single-button function: Send value
With this function, the set value is sent on keypress.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
131 Button left –
Send value, Send percent value, ...
1 Byte Sending the value.
DPT depending on the parameter setting.
+5 Button right ...
Table 54: Communication objects – Single-button function: Send value
