Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.2.1.9 Master-Slave operation
The following is a short description of the settings. For more details, there is a suggested solution on our
website “https://www.mdt-group.com/for-professionals/tips-tricks.html” under „Presence Detector”.
4.2.1.9.1 Light channels
Inlargerrooms,theuseofasinglemotiondetectorisoftennotsufcient.Inordertodetectmotionin
every corner of the room, several detectors have to be used throughout the entire room. Here, however, a
detected motion should always lead to the same settings regardless of the corner of the room in which the
presence was detected. For this purpose, one detector is switched as master and any number of others as
slaves.
The settings for the master-slave control are made in the menu of the respective light channels.
Themasterisconguredasdesiredasafullyorhalf-automaticunit.
A value of 3-5 minutes is recommended for the follow-up time.
Slaves are set as follows:
■ “Brightness” → “independent of brightness”.
■ “Channel operating mode” →“fully automatic”.
■ “Follow-up time Day/Night” →smaller than the delay time in the master (e.g., 1 minute).
■ “Object type for output – light” → “Switch”.
■ “Output object sends → “only ON”.
■ “Output object sends ON cyclically” → A value of 30 seconds is recommended.
The “slaves” send their output object for “switch” to the “external motion (slave)” object of the master.
The following table shows the associated communication object:
No. Name/Object function Length Usage
5 Light channel 1 - Input – External
motion (Slave)
1 Bit Input object for additional slave motion
detector.
+15 Light channel 2 ...
Table 33: Communication objects – Light channels: Master / Slave operation
