MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
37 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.2.1.9.2 HVAC channel
The master-slave control can also be applied to the HVAC channel. The settings for the “slave” are the
same as for the slaves for the lighting groups. However, the settings for the brightness values are omitted
for the HVAC channel. The observation windows are to be set according to the individual requirements.
Important: As long as the slave is in its follow-up time, it cyclically sends a “1” to the master. After the last
“1” has been sent to the master, the master’s follow-up time elapses before the master switches off its
output. In this case, the follow-up time of the master and slave are added up.
The following table shows the associated communication object:
No. Name/Object function Length Usage
65 HVAC - Input – External motion 1 Bit Input object for additional slave motion detector.
Table 34: Communication objects – HVAC - Channel: Master / Slave operation
