MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
17 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.2.1.1 Basic settings – Light channel
Light channel
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Active sensors ■ - -
■ 1 -
■ - 2
■ 1 2
Setting which sensors are active for
this channel.
Information about
sensor assignment
When activated (check box selected
with a mouse click), a sketch appears
with information about the positions of
sensors S1 and S2.
Position of sensors
Sensitivity ■ basic settings (General setting)
■ individual
Setting that determines the sensitivity
(triggering, presence) with which the
channel operates.
Only if „Sensitivity“ → „individual“
Trigger sensitivity
“Day”
0 – 8
[6]
Setting the trigger sensitivity.
Level 0 (lowest level) only from DB
V4.4 and from Device HW R2.5
possible.
Trigger sensitivity
“Night”
0 – 8
[3 (low)]
Presence sensitivity 0 – 10
[8 (high)]
Setting the sensitivity when motion is
detected.
Brightness ■ basic setting or object “Switch
dark” is active
■ independent of brightness
Setting how the channel should react
to brightness.
Channel mode ■ fully automatic
■ half automatic
(manual switching)
Setting the operating mode.
Motionlterinstandby ■ not active, no ltering
■ active,ltershortmotions
Activationofamotionlterinstandby
(= output is switched off).
Only in “fully automatic” mode.
Reduction of follow-up
time
■ not active
■ active
Setting whether a shortening of the
follow-up time should be activated.
