MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
18 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Maximum duration for
short time presence
10 s – 30 s
[20 s]
Setting the maximum duration for a
short-term presence.
Follow-up time for
short time presence
10 s – 120 s
[60 s]
Setting the follow-up time for
short-term presence.
Follow-up time “Day” 1 s – 4 h
[3 min]
Setting the follow-up time for Day/
Night mode.
Follow-up time “Night” 1 s – 4 h
[30 s]
Table 14: Basic settings – Light channel
Active sensors
The active sensors can be set for each light channel. This allows the detection range of the channel to be
limited. For example, if only one area in a corridor is to be detected, only one sensor can be activated. The
alignmentofthesensorscanbeidentiedbyactivatingthe“Informationaboutsensorassignment”
parameter.
Sensitivity
With “basic settings”, the values from the “General settings” menu refer.
With the “individual” setting, the values for the sensitivities for the channel can be set manually. The
parameters correspond to those in the “General settings” menu.
Brightness
With “basic setting or object “Switch dark” is active”, brightness refers to the settings in “General
setting” menu. However, this can become brightness-independent via the “Switch dark” object with a “1”
and thus switches at any brightness.
No threshold applies via the “independent of brightness” setting and the channel always switches.
Channel operating mode
■ Fully automatic: Light channel responds if a presence is detected and switches the output. After the
follow-up time has elapsed, the channel switches off again.
■ Half automatic: In this mode, the light channel is switched on via the “External push button short”
object. The light channel then remains switched on up to the point when no more presence is detected.
After the follow-up time has elapsed, the light channel then automatically switches off again.
Follow-up time
This parameter describes the time that elapses after the last detection of a movement until the output is
switched off. The follow-up time can be set differently for Day/Night. For example, with a
follow-up time of 3 minutes, the light would be switched on for at least 3 minutes if motion was detected.
Each new detection leads to a re-triggering and thus a restart of the follow-up time.
