MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
16 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.2 Selection of channels
Two Light channels, one HVAC channel and one Alarm/Message channel can be activated. A separate
menu appears for each activated channel.
The Light channels and the HVAC channel are described in the following chapter. The Alarm/Message
channel is described in a separate chapter, see 4.2.2.1 Alarm/Message channel.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Light channel 1 ■ not active
■ active
Activation/deactivation of the channel.
Light channel 2 ■ not active
■ active
Activation/deactivation of the channel.
HVAC channel ■ not active
■ active
Activation/deactivation of the channel.
Alarm/Message channel /
Direction of movement
■ not active
■ active
Activation/deactivation of the channel
and recognition of the direction of
movement.
Table 13: Settings – Selecting channels
4.2.1 Light channel / HVAC channel
Light channels and HVAC channel differ only in a few “individual” parameters. Therefore, these channels
are described simultaneously below.
