Je bekijkt pagina 34 van 99
Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
34
34
2. level/ 8 functions
▪ not active
▪ active
Activation of the 2nd level.
Level 2, middle buttons
Level 2, lower buttons
▪ not active
▪ Function 1/2, LED 1/2
▪ Function 3/4, LED 3/4
▪ Function 5/6, LED 5/6
▪ Function 7/8, LED 7/8
▪ Function 9/10, LED 9/10
▪ Function 11/12, LED 11/12
Assignment of the functions
including the LEDs to a specific
button pair.
Visible when 2nd level is active.
3. level / 12 functions
▪ not active
▪ active
Activation of the 3rd level.
Visible when 2nd level is active.
Level 3, middle buttons
Level 3, lower buttons
▪ not active
▪ Function 1/2, LED 1/2
▪ Function 3/4, LED 3/4
▪ Function 5/6, LED 5/6
▪ Function 7/8, LED 7/8
▪ Function 9/10, LED 9/10
▪ Function 11/12, LED 11/12
Assignment of the functions
including the LEDs to a specific
button pair.
Visible when 3rd level is active.
Toggle between levels
via scene object
▪ not active
▪ active
Activate level switching via
receiving scenes.
Visible when 2nd level is active.
Scene number for
change to level 1-3
1 - 64
Setting of the scene number for
the level change.
The following settings are available in both display modes
Slap / Cleaning function
▪ not active
▪ active
Activates the Slap- and Cleaning
function
Reaction time on keypress
▪ fast
▪ medium
▪ slow
Sets the debouncing time of the
buttons
Time for long keypress
0,1 s – 30 s
[0,4 s]
Setting from when a long
keystroke is detected
Table 20: Settings – Button / Function setting
By means of a mapping function, button functions that have been set up can be easily assigned to
other sensor surfaces/buttons. There is no need for time-consuming reprogramming.
The functions are defined first. These can be set either as "single buttons" or as "grouped buttons". A
separate menu then appears for each activated function, in which the function can be configured.
Within the setting of the levels, each function can be assigned to specific buttons as desired. If, for
example, "Function 1/2" is changed from "Level 1, upper buttons" to "Level 2, lower buttons", the
configuration of the function is retained. Only the group addresses must then be reconnected.
Important:
- A function may only be assigned to one button pair at a time. If a function is accidentally
assigned twice, the following message appears in the ETS:
- With the assignment of the functions, the corresponding LEDs are also always taken over.
