Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
33
33
The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Function 1/2 – 11/12
▪ not active
▪ single-button function
▪ two-button function
Setting whether the functions are
to operate in single or two-button
mode.
Display mode
▪ 6 functions / 1-2 levels
▪ 4 functions / 1-3 levels
Setting the display mode.
Display mode: 6 functions / 1-2 levels
1. level / 6 functions
Always displayed, no parameter
Level 1, upper buttons
Level 1, middle buttons
Level 1, lower buttons
▪ not active
▪ Function 1/2, LED 1/2
▪ Function 3/4, LED 3/4
▪ Function 5/6, LED 5/6
▪ Function 7/8, LED 7/8
▪ Function 9/10, LED 9/10
▪ Function 11/12, LED 11/12
Assignment of the functions
including the LEDs to a specific
button pair.
2. level / 12 functions
▪ not active
▪ active
Activation of the 2nd level.
Level 2, upper buttons
Level 2, middle buttons
Level 2, lower buttons
▪ not active
▪ Function 1/2, LED 1/2
▪ Function 3/4, LED 3/4
▪ Function 5/6, LED 5/6
▪ Function 7/8, LED 7/8
▪ Function 9/10, LED 9/10
▪ Function 11/12, LED 11/12
Assignment of the functions
including the LEDs to a specific
button pair.
Toggle between levels
▪ via hidden lower buttons
▪ via scene object
▪ via hidden lower buttons and
scene object
Setting for how to switch between
the different levels.
Only shown if 2nd level is active.
Scene number for
change to level 1/2
1 - 64
Setting of the scene number for
the level change.
Only visible when switching via
scene object.
Change to Standby
level after page change
via hidden buttons
▪ not active
▪ active
Setting whether the device should
fall back to the Standby level.
Only visible when switching via
hidden buttons.
Time for automatic
page switch
1 … 255 s
[10 s]
Setting the time for the page
switch.
Visible if "Change..." is active.
Display mode: 4 functions / 1-3 levels
1. level / 4 functions
Always displayed, no parameter
Level 1, middle buttons
Level 1, lower buttons
▪ not active
▪ Function 1/2, LED 1/2
▪ Function 3/4, LED 3/4
▪ Function 5/6, LED 5/6
▪ Function 7/8, LED 7/8
▪ Function 9/10, LED 9/10
▪ Function 11/12, LED 11/12
Assignment of the functions
including the LEDs to a specific
button pair.
