Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
44
44
Functional principle:
The " Shift value" function shifts the set datapoint type within the set limits. When the "Down" key is
pressed, the set step size is subtracted from the last value and when the "Up" key is pressed, the set
step size is added to the last value.
Lower/Upper limit:
The value is shifted within these limits. The function never falls below the lower limit value and never
exceeds the upper limit value.
Step Width:
The step width indicates the distance between two sent telegrams. If the value 10% was sent during
the previous transmission, the value 20% is sent with the next "Up" command - with a set step size of
10%..
Repeated sending at pressed key:
Repeated sending while holding down the key allows the function to increase/decrease the value
until the upper/lower limit is reached.
The following table shows the available communications objects:
Number
Name
Length
Usage
0
Push buttons 1/2: –
Percent value, Decimal value
1 Byte
Transmission of the value to be shifted.
DPT depending on the parameter setting
3
Push buttons 1/2: –
Status for display
1 Byte
Receiving of the status value.
DPT depending on the parameter setting
Table 32: Communication objects – Send Values - Subfunction: Shift Values
