Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
43
43
4.6.5.3 Subfunction: Shift Value
Two-Button function
With the function Send values - Shift values, values can be shifted up or down within the set limits.
The following figure shows the available settings:
Figure 21: Settings – Send Values - Subfunction: Shift Values
The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Buttons (1/2) (3/4) shift the
values
▪ down / up
▪ up / down
Setting which key shifts up and
which key shifts down
Datapoint type
▪ 1 Byte (0...100%)
▪ 1 Byte (0…255)
Setting the datapoint type for
the value shift
Lower limit
0 – 100% / 0 – 255
[0%/0]
Setting the lower limit value for
the value shift
Upper limit
0 – 100% / 0 – 255
[100%/255]
Setting the upper limit value for
the value shift
Step width
1 – 100% / 1 – 255
[10%/10]
Setting the step width between
two sending commands
Repeated sending at
pressed key
▪ not active
▪ active
Activating the transmission
repetition while holding down
the key
Repetition time
200 ms – 3 s
[1 s]
Repetition time between two
telegrams with pressed key
Table 31: Settings – Send Values - Subfunction: Shift Values
