8/22 Rev. R 132617 ©2022 Refrigerated Solutions Group. All rights reserved.

46

WALK-IN MAINTENANCE

Using small pieces of electrical tape, fasten the heater wire in place. Lift the heater wire at each corner and apply three

thicknesses of electrical tape around the insulation over a length of approximately 3".

Follow by forming a small loop at each corner to permit expansion and

contraction of the heater wire without strain at these points. After the loops

are formed, tape them in place with a short strip of electrical tape.

The heater wire should be relatively straight in the head jamb and in the

side jambs, but all excess heater wire must be taken up in the

THRESHOLD AREA ONLY by forming a "zig-zag" configuration. Make

sure that this configuration will be accommodated by the width of the

raceway in the bottom plate or threshold. The extra length of heater wire

concentrated in the threshold will produce more heat per foot in the

threshold than in the jambs.

After the heater wire is in place, tape it down where necessary with short

strips of electrical tape to prevent the heater wire from interfering with the

replacement of the chrome trim.

STAINLESS STEEL TRIM REPLACEMENT

Start replacing the stainless steel trim

with the head trim section. Hold in

place while replacing the three

screws. Install the right and left trim

in a similar manner. The trim should

easily be replaced by hand.

THRESHOLD REPLACEMENT

Place the threshold in its original location and replace all the screws in their original locations. Reminder:

The hardboard needs to be in place before replacing the threshold. After the threshold is secured, apply a

3/16" bead of silicone sealant at both ends of the threshold where they meet the side jambs. With a wet

finger, smooth out the silicone fillet for a neat, professional looking job.
