20 Martin

P3 PowerPort 2000 and 500 IP Safety, Installation and User Manual

Connecting the hybrid link to fixtures

To connect the hybrid (combined data and 48 VDC power) cable:

1. If the connections compartment is not already open, open it as described in the previous section.

2. The hybrid OUT cable gland is immediately to the right of the two mains power cable glands (see P in

Figure 5). The cable entry (A in Figure 6) is glued into the housing, so do not try to turn it. Loosen the

hybrid OUT cable gland’s compression nut B.

3. Take the hybrid cable that is connected to the chain of lighting fixtures and pass it through the hybrid

OUT cable gland P and into the connections box. Loosen the hybrid cable clamp Q and pass the

cable through it.

4. Strip enough insulation from the thick red and black DC power wires in the power cable to ensure

correct conductivity inside the quick-connectors without leaving any bare copper visible outside the

connectors. Fasten the DC power wires into the DC power quick-connectors G as follows:

• Red, positive (+) wire to the connector marked 48V+

• Black, negative (-) wire to the connector marked 48V-.

Lift up the orange lever on each quick-connector, put the stripped wire into the connector, then push

the orange lever back down and check that the wire is held securely in the connector.

5. There are four data wires colored orange, orange/white, green and green/white in the hybrid cable. Do

not strip insulation from these wires.

6. Untwist the data wires, lift the levers in the orange hybrid cable data connectors F and slide the wires

into the connectors, respecting the color coding of the wires and the connectors (green to green,

green/white to green/white etc.). Push the levers on the orange connectors all the way down firmly

and check that the wires are held securely.

7. Twist the strands in the data wire shield together to form one twisted wire, loosen one of the screws in

the green screw terminal block at F in Figure 5 and insert this wire into that hole in the terminal block.

Insert the shield from the direction indicated by the arrow next to the terminal. Tighten the screw and

check that the shield is held securely in the terminal block. One hole in this green terminal block can

be left empty.

8. Tighten cable clamp Q onto the hybrid OUT cable until the cable is held tightly.

9. Tighten the compression nut B on the hybrid OUT cable gland P until the cable is held tightly in the

cable gland.

Connecting network data cables

P3 PowerPort devices have two network data ports: port A and port B. It makes no difference which port

you use for data IN from the controller and which port you use for data THRU to other compatible devices.

To connect a network data input cable:

1. If the connections compartment is not already open, open it as described earlier.

2. The data A and B cable glands are immediately to the right of the hybrid cable gland at R and T in

Figure 5. The cable entries (A in Figure 6) are glued into the housing, so do not try to turn them.

Loosen the compression nut B of cable gland R.

3. See Figure 5. Take the data input cable and pass it through the cable gland R and into the

connections box. Loosen the data cable clamp S and pass the cable through it.

4. There are eight data wires colored orange, orange/white, green, green/white, blue, blue/white, brown

and brown/white in the network cable. Do not strip insulation from these wires.

5. Untwist the data wires, lift the levers in the orange network cable data connectors H and slide the

wires into the connectors, respecting the color coding of the wires and the connectors (green to green,

green/white to green/white etc.). Push the levers on the orange connectors all the way down firmly

and check that the wires are held securely.

6. Twist the strands in the data wire shield together to form one twisted wire, loosen one of the screws in

the green screw terminal block between H and I in Figure 5 and insert this wire into that hole in the

terminal block. Insert the shield from the direction indicated by the arrow next to the terminal. Tighten

the screw and check that the shield is held securely in the terminal block.

7. Tighten the cable clamp S onto the data cable until the cable is held tightly.
