28 Exterior PixLine™ User Manual
Status display
To display a Exterior PixLine fixture’s status, swipe the magnet over the sensor once. The first four and last
two LEDs on the fixture will give one of the indications listed in the tables below for a few seconds.
Testing, rebooting and returning to defaults
The tables below list the functions of the magnetic ‘control button’ on each Exterior PixLine fixture.
Test patterns are stored in onboard memory. This lets you test the LEDs without an external controller, but
test patterns can also be called up on P3 system controllers, the P3 PowerPort 1500 and the P3 PowerPort
1000 IP.
Color Output Indication Action required
Blue Constant
Busy (e.g. booting up or writing to
flash memory).
Wait a moment for normal operation
to be resumed.
Red Constant
Error. The Exterior PixLine has
encountered a fatal error and can
not run.
Perform a factory reboot, followed by
a firmware upload.
Red Flashing No control source detected.
Connect a P3 system controller or
DMX controller to the network.
Green Flashing
Ready. Exterior PixLine connected
to P3 controller but not mapped onto
the canvas.
Set up the P3 controller to use the
Exterior PixLine.
Green Constant Running normally in P3 mode. None.
Cyan Flashing
Ready. Exterior PixLine connected
to DMX controller but not receiving
valid DMX data.
Send DMX data (if flashing cyan
continues although you are sending
data, check that DMX controller is
connected correctly and configured
with Exterior PixLine's DMX
address).
Cyan Constant Running normally in DMX mode. None.
Table 7: Status information
Action Function
Quick swipe The first swipe displays status as shown in Table 7 for a few seconds.
The next swipes display the following test patterns on the LEDs (each
swipe scrolls to the next pattern):
- Calibrated white
- Full red
- Full green
- Full blue
- Scrolling gradient
- Dimmed (20% uncalibrated white)
Hold magnet over
‘button’ until LEDs
1-4 light blue
Reboot the Exterior PixLine.
Hold magnet over
‘button’ until LEDs
1-4 light white
Return the Exterior PixLine to its default factory firmware.
Table 8: Magnetic ‘control button’ functions
