Front panel
1. Power switch. The mains power on-off switch is
at bottom front left. If the device is in sleep
mode (page 30), you can wake it up using Vu-
Net (page 36) or by switching this power switch off,
pausing for a second or two and then switching it on
again.
2. Graphical display. The home screen shows an
overview of the channel allocation. When you
view the input (page 18), output (page 24) or
utility (page 30) menus, the menu item names
appear on the top line and the parameters to edit
appear on the bottom line.
If SECURE appears (either top right or bottom
left), this means that the amplifier is in secure
mode (page 16) and you won't be able to edit any
settings.
To change the contrast, see Screen
contrast (page 32).
3. Status Indicators. The ONLINE indicator has three
states:
▪ Off – The unit isn't connected to Vu-
Net (page 36).
▪ Flashing – The unit is searching for an IP address.
If the unit fails to find one, it will assign itself an
IP address automatically and the indicator will stop
flashing.
▪ On – The unit is connected to Vu-Net (page 36).
The AES3 IN indicator is on when one or more of the
inputs is configured to an AES3 source.
The DANTE indicator is on when one or more of the
inputs is configured to Dante.
4. SELECT (the left-hand dial) allows you to switch
between parameters.
5. ADJUST (the right-hand dial) allows you to edit
parameters.
When you edit a parameter, the
parameter changes straight away.
There is no separate step to save
changes.
6. Menu buttons. When you press INPUT, OUTPUT or
UTILITY, the button illuminates to show that you've
selected this menu. The up▲and down▼buttons
illuminate to show that you can use these buttons
to page through the menu. The ENTER button
illuminates whenever you need to press the ENTER
button to confirm a change.
The OUTPUT button displays a menu of parameters
associated with each output channel (page 24).
The INPUT button displays a menu of parameters
associated with each input socket or each input DSP
channel (page 18). If you press INPUT or OUTPUT
several times, you scroll through the input or output
channels. After the last channel, you exit the menu
and return to the home screen. The UTILITY button
displays
miscellaneous parameters (page 30). The
menus are mutually exclusive – if you press one of
iK41 User Guide
9
