these buttons you switch to that menu. To exit from a
menu, press UTILITY.
To lock the front panel (to stop
tampering), see Secure mode (page
16).
7. Input Signal Indicators. A set of five indicators
show Signal, –12, 0dBu, +6 and +12 and CLP/(mute)
for each of the DSP inputs A, B, C and D. The
Signal indicator shows the signal is greater than
about –40dBu. The CLP/(mute) indicator warns
you of input overload and operates at 1dB before
clip. This indicator also shows whether the input is
muted (page 18).
8. Limiter Indicators. The output indicators show the
status of the limiter and the output level. The level
shown is the level before the limiter, referenced to the
limiter threshold.
The Signal indicator shows when a signal is present
on the output.
The –6dB indicator shows that the signal has reached
6dB below the limiter threshold.
The Limit indicator shows that the threshold of that
output channel has been reached.
Bridge Indicator. This illuminates when the channel
pair is in
Bridge mode (page 26). The amplifier uses
the settings for the left channel of the pair.
Amplifier Indicator. This indicates when the amplifier
protection systems are reducing the gain to keep the
parameters of the amplifier within specification, or
when the channel is clipping.
Driver Indicator. This indicates a signal 6dB higher
than the limiter threshold, or that the threshold of
the excursion limiter has been exceeded, or that the
thermal limiter is active. Please note that because
of the long release time of the thermal limiter, this
indicator may remain illuminated for several seconds
after signal on that channel is reduced.
9. Mute Buttons. DSP output mute status is indicated
and controlled by an illuminated button for
each channel. If the amplifier protection systems
automatically mute a channel, the mute button
flashes.
iK41 User Guide
10
