AQ210 Technical Specifications
TYPE Ultra-compact, dual driver, low profile, vented sub-
bass
FREQUENCY
RESPONSE (1)
50Hz-150Hz ± 3dB
DRIVERS 2 x 10” (250mm)/3” (75mm) voice coil LF drivers
RATED POWER (2) 600W AES, 2400W peak
RECOMMENDED AMPLIFIER 400-800W into 4 ohms
SENSITIVITY (6), (3) 98dB (open space), 104dB (half space)
MAXIMUM SPL (calculated @ 1m) 122dB continuous, 128dB peak (open space)
128dB continuous, 134dB peak (half space)
NOMINAL IMPEDANCE 4 ohms
CROSSOVER 120Hz active (via AQX controller)
ENCLOSURE 60 litre, braced 18mm MDF
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 20 amp push-lock
FITTINGS
OPTIONS Passive low pass filter
DIMENSIONS (W) 670mm x (H) 335mm x (D) 437mm
(W) 26.4ins x (H) 13.2ins x (D) 17.2ins
WEIGHT 30kg (66lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
