AQ112 Technical Specifications
TYPE Ultra-compact, vented sub-bass
FREQUENCY
RESPONSE (1)
48Hz-150Hz ± 3dB
DRIVERS 12” (300mm)/3” (75mm) voice coil LF driver
RATED POWER (2) 400W AES, 1600W peak
RECOMMENDED AMPLIFIER 400-800W into 4 ohms
SENSITIVITY (6), (3) 96dB (open space), 102dB (half space)
MAXIMUM SPL (calculated @ 1m) 120dB continuous, 126dB peak (open space)
126dB continuous, 132dB peak (half space)
NOMINAL IMPEDANCE 8 ohms
CROSSOVER 120Hz active (via AQX controller)
ENCLOSURE 52 litre, braced 18mm MDF
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 20 amp push-lock
FITTINGS
OPTIONS Passive low pass filter
DIMENSIONS (W) 475mm x (H) 385mm x (D) 410mm
(W) 18.7ins x (H) 15.2ins x (D) 16.2ins
WEIGHT 21.5kg (47lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
