AQ15 Technical Specifications
TYPE Compact, two-way passive, vented trapezoid
FREQUENCY RESPONSE (1) 55Hz-18kHz ± 3dB
DRIVERS 15” (380mm) bass driver
1.4” (35mm) exit HF compression driver
RATED POWER (2) 400W AES, 1600W peak
RECOMMENDED
AMPLIFIER
400-1000W into 4 ohms
SENSITIVITY (6) 99dB
MAXIMUM SPL (7) 123dB continuous, 129dB peak
NOMINAL IMPEDANCE 8 ohms
DISPERSION (-6dB) 80º horizontal, 50º vertical
CROSSOVER 1.6kHz passive
ENCLOSURE 63 litre, braced 18/24mm MDF
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 20 amp push-lock
FITTINGS 12 x M8 inserts for flyware
OPTIONS 150W 100/70V line transformer
DIMENSIONS (W) 469mm x (H) 690mm x (D) 415mm
(W) 18.5ins x (H) 27.2ins x (D) 16.4ins
WEIGHT 33.5kg (74lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
