AQ12 Technical Specification
TYPE Compact, two-way passive, vented trapezoid
FREQUENCY RESPONSE (1) 62Hz-18kHz ± 3dB
DRIVERS 12” (300mm) bass driver
1” (25mm) exit HF compression driver
RATED POWER (2) 300W AES, 1200W peak
RECOMMENDED
AMPLIFIER
300-800W into 4 ohms
SENSITIVITY (6) 97dB
MAXIMUM SPL (7) 120dB continuous, 126dB peak
NOMINAL IMPEDANCE 8 ohms
DISPERSION (-6dB) 80º horizontal, 50º vertical
CROSSOVER 2.2kHz passive
ENCLOSURE 36 litre, braced 18mm MDF
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 20 amp push-lock
FITTINGS 6 x M8 inserts for bracket
1 x M8 insert for safety point
OPTIONS 150W 100/70V line transformer
DIMENSIONS (W) 354mm x (H) 560mm x (D) 364mm
(W) 14ins x (H) 22ins x (D) 14.3ins
WEIGHT 20kg (44lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
