AQ10 Technical Specifications
TYPE Compact, two-way passive, vented trapezoid
FREQUENCY RESPONSE (1) 65Hz-20kHz ± 3dB
DRIVERS 10” (250mm) bass driver
1” (25mm) exit HF compression driver
RATED POWER (2) 300W AES, 1200W peak
RECOMMENDED
AMPLIFIER
300-600W into 4 ohms
SENSITIVITY (6) 96dB
MAXIMUM SPL (7) 119dB continuous, 125dB peak
NOMINAL IMPEDANCE 8 ohms
DISPERSION (-6dB) 90º horizontal, 50º vertical
CROSSOVER 2.7kHz passive
ENCLOSURE 27 litre, braced 18mm MDF
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 20 amp push-lock
FITTINGS 6 x M8 inserts for bracket
1 x M8 insert for safety point
OPTIONS 150W 100/70V line transformer
DIMENSIONS (W) 323mm x (H) 493mm x (D) 325mm
(W) 12.7ins x (H) 19.4ins x (D) 12.8ins
WEIGHT 17kg (37lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
