AQ212 Technical Specifications
TYPE Compact, dual driver, low profile, vented sub-bass
FREQUENCY
RESPONSE (1)
48Hz-150Hz ± 3dB
DRIVERS 2 x 12” (300mm)/3” (75mm) voice coil LF drivers
RATED POWER (2) 800W AES, 3200W peak
RECOMMENDED AMPLIFIER 400-1200W into 4 ohms
SENSITIVITY (6), (3) 99dB (open space), 105dB (half space)
MAXIMUM SPL (calculated @ 1m) 123dB continuous, 129dB peak (open space)
129dB continuous, 135dB peak (half space)
NOMINAL IMPEDANCE 4 ohms
CROSSOVER 120Hz active (via AQX controller)
ENCLOSURE 100 litre, braced 18mm MDF
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 20 amp push-lock
FITTINGS
OPTIONS Passive low pass filter
DIMENSIONS (W) 860mm x (H) 385mm x (D) 437mm
(W) 33.9ins x (H) 15.2ins x (D) 17.2ins
WEIGHT 39kg (86lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
