www.marshall -usa.com
35 36
CV630-BI/WI/ND3/ND3W
User Manual
4 Encode Format
Display Encode Format
5 Multicast
Multicast Setting
It is suggested to enable Multicast when the number of users online
watching the image simultaneously is more than 4
6 Discovery Serve Check to enter the Server IP address
7 Apply
After the setting has been modified, select this button to apply the setting
No Item Function Descriptions
1 Camera ID
Change camera ID here
Camera IDs are limited to 1 - 12 characters
Please mix uppercase and lowercase letters or numbers for
characters. Special symbols such as “/” and “space” cannot be used
<Remark> Modifying this field will modify the Onvif device name
synchronously
2 Location
Modify the location of the camera, such as Room 1
Camera location is limited to 1 - 11 characters
Please mix uppercase and lowercase letters or numbers for
characters. Special symbols such as “/” and “space” cannot be used
< Remark > Modifying this field will modify the Onvif device location
synchronously
3 Apply After the setting has been modified, select this button to apply the setting
4 Encode Format
Display Encode Format
5 Multicast
Multicast Setting
It is suggested to enable Multicast when the number of users online
watching the image simultaneously is more than 4
6 Discovery Serve Check to enter the Server IP address
7 Apply
After the setting has been modified, select this button to apply the setting
No Item Function Descriptions
1 Camera ID
Change camera ID here
Camera IDs are limited to 1 - 12 characters
Please mix uppercase and lowercase letters or numbers for
characters. Special symbols such as “/” and “space” cannot be used
<Remark> Modifying this field will modify the Onvif device name
synchronously
2 Location
Modify the location of the camera, such as Room 1
Camera location is limited to 1 - 11 characters
Please mix uppercase and lowercase letters or numbers for
characters. Special symbols such as “/” and “space” cannot be used
< Remark > Modifying this field will modify the Onvif device location
synchronously
3 Apply After the setting has been modified, select this button to apply the setting
1
2
3
6.2.5 System – Output
1
2
3
4
5
6
7
No Item Function Descriptions
1 Resolution
Set the resolution of the camera
After switching to the resolution, the camera will restart. Please refresh
the browser
2 Output Source
According to the output resolution, you can select HDMI+NDI, HDMI +
Streaming or HDMI + UVC output
<Remark>
When it is set to UVC output, 3840 x 2160 30p or lower
resolutions are supported
< Remark > UVC does not support 1080i.
3 HDMI Format
Select YUV422 / YUV420 / RGB
<Remark> When it is set to YUV420, 3840 x 2160 60p/ 59.94p/ 50p
resolutions are supported
4 Color Space Set the standard for color gamut Standard Profile/ REC.709/ BT.2020
5 UVC
Available when System-Output-Output Source is set to HDMI+UVC
n Encode Format：
Ø 3840x2160 29.97 / 25 fps: H.264
Ø Less than 1080p (inclusive): H.264/MJPEG
n Resolution: It is shown based on System-Output-Output Source
Frame Rate: 3840 x 2160 can only select the highest 29.97 fps
6
Overlay
Set the stream to display “date and time” or “custom content” and to
display location
7 Apply/ Cancel Apply/ Cancel Setting
www.marshall-usa.com
6.2.4 System – Output
