-30-
• Hold the machine by its handles and place the front
part of its base plate onto the workpiece.
• Switch on the portable circular saw (see chapter
6.2) and slide the machine evenly forward in the
direction of the cut.
• When the cut is completed, switch off the saw by
releasing the switch trigger 8 (Fig. 2)
6.8 Sawing with the parallel stop
The parallel stop 17 (Fig. 2) serves to cut parallel to an
already existing edge. The limit stop can be attached
to the left or right of the machine. The cutting range on
the right-hand side amounts to 47 - 200 mm (1 27/32 –
7 7/8 in.) and on the left-hand side to 195 - 405 mm (7
43/64 – 15 15/16 in.). In the range 195 – 260 mm (7
43/64 – 10 15/64 in.), the machine must be set approx.
10 mm (25/64 in.) to the top, so that the machine can
be pushed under the motor casing.
• You can adjust the cutting width after releasing the
wing screws 9 (Fig. 2) by moving the limit stop
accordingly and afterwards retightening the wing
screws.
In addition, by simply turning it around (guide face for
the workpiece edge points upwards), the parallel stop
can also be used as double support to improve
guidance of the portable circular saw. Now the
machine can be guided along a lath that is fastened on
the workpiece.
6.9 Working with the roller edge guide
The roller edge guide serves to work parallel to an
already existing edge. The limit stop can be attached
to the left or right of the machine. The cutting range on
the right-hand side amounts to approx. 12 - 48 mm
(15/32 – 1 57/64 in.) and on the left-hand side to
approx. 40 – 280 mm (1 37/64 – 11 15/64 in.).
• You can adjust the cutting width after releasing the
wing screws 9 (Fig. 2) by moving the limit stop
accordingly and afterwards retightening the wing
screws.
7 Service and maintenance
Danger
Pull the power plug during all
service work.
MAFELL machines are designed to be low in
maintenance.
The ball bearings used are greased for life. When the
machine has been in operation for a longer period of
time, we recommend to hand the machine in at an
authorised MAFELL customer service shop for
inspection.
Only use our special grease, order No. 049040 (1 kg
tin) for all greasing points.
7.1 Storage
Clean the machine thoroughly if the machine is not
used for a longer period of time. Spray blank metal
parts with a rust-proofing agent.
8 Visual signal indication of operating
condition
The colour of the speed adjusting wheel indicates the
machine’s operating state.
As long as the machine is not overloaded in terms of
output, the speed adjusting wheel permanently lights
up green during operation.
If the adjusting wheel permanently lights up red, there
is a defect (see the Chapter Troubleshooting).
