-29-
• Switching off: To switch off, release the gearshift
lever 8. The built-in automatic brake limits the saw
blade slowing time to approx. 5 s. The switch-on
lock automatically takes effect again and secures
the portable circular saw against accidental switch-
on.
6.3 Light
The power tool is equipped with a light module 23 (Fig.
3).
The light module is supplied with power for a certain
period of time as soon as the machine is switched on,
and is then ready for operation.
If the machine is at a standstill for a longer period of
time, the light switches off automatically.
6.4 Cutting depth adjustment
The cutting depth is continuously variable between 0
and 88 mm.
Proceed as follows:
• Press the push-button 11 (Fig. 1) and adjust the
cutting depth with the plunge lever 6.
• The cutting depth can be read off scale 13 on the
cover. The surface of plunge lever 6 with the red
background serves as indicator.
Always set the cutting depth
approx. 2 to 5 mm (5/64 to 13/64
in.) larger than the material
thickness to be cut.
6.5 Setting for bevel cuts
For bevel cuts, the saw unit can be set to any angle
between 0 °and 60°.
• In order to incline it, bring the machine into home
position and support it such that it is possible to tilt
the saw unit.
• Unfasten the wing nut 10 (Fig. 2)
• Adjust the angle according to the scale on the
segment for tilting.
• Afterwards, tighten the wing bolt 10.
6.6 Plunge cuts
Danger
Risk of backlash during plunge
cuts! Prior to plunging, place the
machine with the rear edge of its
base plate against a limit stop
fastened on the workpiece. Keep a
firm hold on the machine handle
during plunging and push the saw
lightly forward!
• Press the push-button 11 (Fig. 1) and put the
machine in the topmost position with plunge lever 6.
• Completely open the retractable saw guard with the
pre-feed lever 1 (Fig. 2), so that the machine can be
placed onto the workpiece to be processed. The
saw blade is now freely suspended above the
material and can be aligned with the marking.
• Switch on the machine and press the plunge lever 6
(Fig. 1) downwards. This causes the saw blade to
plunge vertically into the workpiece. The plunging
depth can be read from scale 13. The riving knife /
splitter swings up and away when the blade enters
the workpiece. As soon as the slit behind the saw
blade is cleared during the forward motion of the
machine, the riving knife reverts to its normal
position.
In case of repetitive plunge cuts of
the same depth, the plunging depth
can be preset.
Proceed as follows:
• Set the machine to the desired cutting depth.
• Open the clamping screw 14 (Fig. 2) and set the
stop bar 16 downwards up to the limit stop.
• Retighten the clamping screw. After completion of
the plunge work, set the stop bar into the top
position.
6.7 Sawing according to tracings
The pivoting part is equipped with a tracing edge for 0°
- 60°. This tracing edge corresponds to the saw blade's
inside. For bevel cuts, the tracing can be viewed
through the opening below the plunge lever 6.
