-28-
• Using the Allen key 5 (bracket Fig. 2), release the
flange screw 18 (Fig. 3) counter clockwise. Now
remove both the screw and the front clamping
flange 12.
• You can now remove the saw blade.
• The clamping flanges must be free of adhering
parts.
• Pay attention to the sense of rotation when inserting
the saw blade.
• Afterwards, push on the clamping flange, apply the
flange screw and tighten it by turning it clockwise.
• Close the retractable saw guard. To do so, press the
locking lever 19 (Fig. 2) downwards.
5.5 Riving knife/splitter
Danger
Pull the power plug during all
service work.
The riving knife / splitter 15 (Fig. 3) prevents the saw
blade from jamming during longitudinal cutting. The
correct distance to the saw blade is shown in (Fig. 4).
• For adjustment purposes, release the screw 4 (Fig.
3) with the Allen key 5 that is included in the supply
(Fig. 2)
• Adjust the riving knife/splitter by moving it in its
longitudinal groove and retighten the screw
afterwards.
5.6 Laying the connection cable
Danger
While working, pay attention to how
the connecting cable is laid. A
poorly laid connecting cable can
impair safety functions and working
functions and come into contact
with the tool.
How to lay the cable is shown in Fig. 5 by way of
example.
Lead the connecting cable away from the machine in
the direction of the cable sleeve. Always keep the
connecting cable as far away as possible from the
working tool. For support, use the Velcro fastener on
the extraction connection.
6 Operation
6.1 Initial operation
Personnel entrusted to work with the machine must be
made aware of the operating instructions, calling
particular attention to the chapter "Safety instructions".
6.2 Switching on and off
• Switching on: Press the switch-on lock 7 (Fig. 2)
forward to unlock it. Then, with the switch-on lock
depressed, press gearshift lever 8.
As this is a switch without locking device, the machine
will only run for as long as this gearshift lever is
pressed.
The built-in electronic system provides for jerk-free
acceleration when the machine is switched on and
under load readjusts the speed to the fixed setting.
In addition, this electronic system adjusts the motor
down in case of overload, i.e. the saw blade will stop.
Switch the machine off then. Then switch the machine
on again and continue sawing at a reduced feed
speed.
The setting wheel 20 (Fig. 2) can be used to adjust the
tool speed in a continuously variable manner between
2250 and 4400 rpm.
Level Speed rpm
1 2250
2 2680
3
3110
4
3540
5 3970
6 4400
Material groups
- Hardwood, softwood, plywood
- Level: 4 - 6
- Coated panel materials
- Level: 4 - 6
- Soft fibre
- Level: 6
