-27-
4 Layout
4.1 Depicted components
(see Fig. 1-3)
(1)
Pre-feed lever
(2) Push-button
(3) Hose connector
(4)
Screw
(5) Hexagon screwdriver
(6) Plunge lever
(7)
Switch-on lock
(8) Shift lever
(9) Wing screws
(10)
Clamping lever
(11) Push-button
(12) Clamping flange
(13)
Scale
(14) Clamping screw
(15) Riving knife/splitter
(16)
Stop bar
(17) Parallel guide fence
(18) Flange screw
(19)
Locking lever
(20) Setting wheel
(23) Light module
5 Setting / adjustment
5.1 Mains connection
Prior to commissioning make sure that the mains
voltage complies with the operating voltage stated on
the machine's rating plate.
5.2 Chip extraction
Danger
Substances that are harmful to
health must be taken up with an M-
suction device.
Connect the machine to a suitable external dust
extractor during all work generating a considerable
amount of dust. The air velocity must be at least 20 m/s
(65.6 ft / sec.).
The internal diameter of hose connector 3 (Fig. 1) is 35
mm ( 1 3/8 in.).
5.3 Saw blade selection
Use a sharp tool to obtain a good cut quality and select
a tool from the following list according to material and
application:
For cuts along and across the grain in soft or hard
wood:
- Circular saw blade carbide Ø 237 x 2.5 x 30 mm, 24
teeth
For cuts especially along the grain in soft or hard
wood:
- Circular saw blade carbide Ø 237 x 2.5 x 30 mm, 12
teeth
For cuts especially across the grain in soft or hard
wood:
- Circular saw blade carbide Ø 237 x 2.5 x 30 mm, 56
teeth
Cutting of wood fibre insulation materials:
- Circular saw blade carbide Ø 237 x 2.5 x 30 mm, 56
teeth
Cutting of synthetic materials (polystyrene):
- Circular saw blade carbide Ø 237 x 2.5 x 30 mm, 24
teeth
5.4 Saw blade change
Danger
Pull the power plug during all
service work.
Risk of injury even if the saw wire is
standing still. Wear protective
gloves!
• Press the push-button 2 (Fig. 2) and pull the locking
lever 19 upwards. Now the saw shaft is locked in
position and the gearshift lever locked. You can lock
the retractable saw guard in an open position with
the aid of the pre-feed lever 1 (Fig. 2) or manually
to make the tool change easier.
