SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
Caséta by Lutron Load Controls
369987l 15 2.24.23
Wiring Diagrams - Switches (continued)
3-Way Installation (load is controlled from 2 locations) (continued)
Option 1: With mechanical switch (continued)
Location 2
Location 2
PD-5ANS,
PD-6ANS
or DVRF-5NS
1
Mechanical
Switch
1
Brass
Brass
Load
Line / Hot
Neutral
GreenWhite
Ground
Ground
Black Red
2
Blue
120 V~
50 / 60 Hz
Black
Jumper
wire
PD-5ANS, PD-6ANS, DVRF-5NS (Load-side)
Ground
GreenWhite
Line / Hot
Neutral
120 V~
50 / 60 Hz
Black
Red
2
Blue
Brass
Jumper wire
Black
Brass
Load
PD-5ANS,
PD-6ANS
or DVRF-5NS
1
PD-5ANS, PD-6ANS, DVRF-5NS (Line-side)
Mechanical
Switch
1
Ground
Location 1
Location 1
1
Location of Caséta switch and mechanical switch may be reversed.
2
The red wire must be connected to the load and the black wire must be connected to Line / Hot. The switch will not work if the wires are reversed.
15
