SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
Caséta by Lutron Load Controls
369987l 14 2.24.23
Wiring Diagrams - Switches (continued)
3-Way Installation (load is controlled from 2 locations)
Option 1: With mechanical switch
PD-5WS-DV
1
Mechanical
Switch
1
Brass
Brass
LUT-MLC
2
Load
Line / Hot
Location 1
Location 2
Neutral
Green
Ground
Ground
Black
Red
Blue
120 / 277 V~
50 / 60 Hz
Black
Jumper
wire
PD-5WS-DV (Load-side)
1
Location of Caséta switch and mechanical switch may be reversed.
2
A LUT-MLC ensures proper function when LED, fluorescent, or ELV loads are used. Install the LUT-MLC inside a load fixture or in a separate junction box within
the circuit.
Line / Hot
Neutral
120 / 277 V~
50 / 60 Hz
Mechanical
Switch
1
PD-5WS-DV
1
Black
Location 1 Location 2
Ground
Green
Red
Blue
Brass
Black
Brass
Ground
LUT-MLC
2
Load
PD-5WS-DV (Line-side)
(continued on next page…)
14
