10
XP800
Follow strictly the maintenance program. Not meeting the maintenance program will cause forfeiture of the warranty
A. Clean all external surfaces and hidden points with fresh water and soft cloth or nonabrasive sponge to remove all salt layers. Do
not use chlorine, bleach or acid solutions to clean the windlass as this will damage the INOX parts and the seals. Apply metal polish
compound and coat all INOX parts to remove oxidation and renew the bright nish of the material.
B. Grease the rotating parts with yellow marine grease that is nonconductive. Particularly, the main shaft threads of the gear motor and
clutch cones. Check for evidences of corrosion and mechanical stresses. Apply anti-seize grease to the threads of the shaft and gypsy
cap, the studs and base, as well as to the chain cap and the screws that seal the base.
C. Check that crimps are secured on the cables exiting the water gland of the gear motor. Test the voltage drop at the terminals.
D. Replace the main seal on the base.
E. Remove the anchor windlass from the deck to clean the salt under the base and seal again.
F. The gearmotor consists of the planetary gearbox which is lled with grease lubrication therefore no oil is required.
6 MAINTENANCE
USE OF THE YACHT (MONTHS)
LESS THAN 2 FROM 2 UP TO 6 MORE THAN 6 CHARTER
EVERY 3 MONTHS A - A A - B A - B
EVERY 6 MONTHS A - B
EVERY 12 MONTHS A - B - C C C C - D
EVERY 24 MONTHS D D E
EVERY 36 MONTHS D - E E E
Disconnect power to the anchor windlass before any maintenance.
6.1 Maintenance programme
1. By turning clockwise the handle, remove the gypsy cap (#212).
2. Remove the three M6 screws from the base that connect the
chain cap (#1042) to the base. Remove the chain cap and the
stripper to access the gypsy.
3. Slip off from the shaft the gypsy, and the lower clutch cone.
4. Wash with running water. DO NOT USE WATER UNDER
PRESSURE.
5. Check that there is no evidence of corrosion or mechanical
stresses.
6. Reassemble by proceeding in the reverse order, remembering to
lubricate threads and all moving parts with grease.
6.2 Gipsy maintenance/replacement
LOFRANS'
