29 GB/MT
Initial use / Installing the LED strip / Maintenance and cleaning / Disposal
Trimming / connecting
the LED tape
The LED tape may be trimmed to size or connected.
DANGER TO LIFE BY
ELECTRIC SHOCK!
Disconnect the LED strip from the power supply be-
fore performing any work on the LED strip
3
. Un-
plug the mains adapter
2
from the socket to do so.
Choose the desired LED strip length.
Note: Ensure that you trim the LED strip in the
right place. The cutting point lies exactly
between
the plus and minus pole and is marked with a
black line and a scissors icon (see Fig. B).
Shorten the LED strip
3
using a pair of scissors.
Then press both ends of the LED strip
3
onto
the displacement contact of the plug connection
5
(see Fig. C). Ensure the correct polarity
(+ to + / - to -).
Then press one end cap
6
at a time onto the
ends of the plug connection
5
(see Fig. C).
Check the correct positioning.
Be sure to cover the open end of the LED tape
3
with the adhesive strip
7
if you do not wish to
connect the end after trimming the tape (see
Fig. E).
Installing the LED strip
Note: Ensure that the installation area is clean,
grease-free and dry. Otherwise the functionality
of the adhesive strip may be impaired.
Note: Ensure that a plug socket is located in close
proximity to the installation area.
Note: Avoid excessive bending of the LED strip
3
.
Choose a suitable installation area (window etc.).
Remove the protective foil from the reverse side
of the LED strip
3
.
Note: Be sure to start removing the protective
film at the supply cable end. When removing
the protective film, be careful not to remove the
adhesive film.
Stick the LED strip
3
with the adhesive strip
onto
the installation area and press it on firmly.
Remove the protective foil from the reverse side
of the cable hold
4
(see Fig. D).
Stick the cable hold
4
onto the desired position.
Squeeze the mains cable
1
into the cable
hold
4
.
Insert the mains adapter
2
into the plug socket.
Switch the LED strip on or off using the in-line
switch
8
.
Your LED strip is now ready to use.
Maintenance and cleaning
DANGER TO LIFE FROM
ELECTRIC SHOCK!
Disconnect the LED strip from the power supply be-
fore performing any work on the LED strip
3
. Un-
plug the mains adapter
2
from the socket to do so.
Do not use solvents, petrol, etc. This would
cause damage to the luminous LED strip.
Use a dry, lint-free cloth to clean the LED strip
3
.
Disposal
The packaging is made entirely of recyclable mate-
rials, which you may dispose of at local recycling
facilities.
The packaging is made entirely of recy-
clable materials, which you may dispose
of at local recycling facilities.
b
a
Observe the marking of the packaging
materials for waste separation, which
are marked with abbreviations (a) and
numbers (b) with following meaning:
1–7: plastics / 20–22: paper and fibre-
board / 80–98: composite materials.
To help protect the environment, please
dispose of the product properly when it
has reached the end of its useful life and
not in the household waste. Information
on collection points and their opening
hours can be obtained from your local
authority.
Safety / Initial use
