The cable gland
14
has to be
loosened, then run the connec-
tion cable (not include in the
product), type H05RN-F 3G
1.0 mm
2
, through the cable
gland
14
and into the connec-
tion box
7
.
Open the terminal block
11
by
using a slot head screw driver
to loosen the screws. Attach
ferrules to the wires of the con-
nection cable. Also attach the
cord anchorage
12
to the con-
nection cable and use pliers to
tighten it on the connection ca-
ble (Fig. B). Connect them with
the terminal block
11
in the
connection box
7
. Pay atten-
tion to the markings on the ter-
minal block
11
(L for live, N
for neutral and
for the earth
wire) (Fig. B). Close the termi-
nal block
11
again by fasten-
ing the screws.
Close the connection box
7
again by fastening the fixing
screws
15
.
Now use the screw driver (cross
type) to attach the spotlight
1
to the mounting bracket
6
by
using the previously removed
locking screws
2
, spring
washers
3a
and tooth lock
washers
3b
(Fig. A).
Align the spotlight
1
into the
desired direction. For this, you
may need to slacken the fasten-
ing screw
8
. After finish the
alignment, tighten the fastening
screw
8
again, to ensure a
secure hold.
Reinsert the fuse or switch the circuit
breaker back on. Your product is
now ready to use.
Start-up
Adjusting the
motion detector
Depending on the pre-adjustments
of the motion detector
9
, the spot-
light
1
will switch itself on for a
certain period of time as soon as
the motion detector
9
detects
movement. These pre-adjustments
are made using the three controllers
on the underside of the motion
detector
9
(Fig. C).
