Je bekijkt pagina 10 van 90
10 GB/CY
Before use
Note: Remove all packaging
materials from the product.
Installation
Make sure you will not be drill-
ing into electrical, gas or water
l
ines inside the wall. Use a power
drill to drill the holes into the
brick wall. Always observe all
safety instructions for the power
drill in the manual for the power
drill. Death or injury due to
electric shock may otherwise
result.
When selecting the mounting loca-
tion, pay attention to the following:
Make sure that the spotlight
1
illuminates the desired area.
You can move the spotlight
1
vertically.
Make sure the motion detector
9
covers the desired area.
The motion detector
9
has a
maximum coverage range of
12 m, with a coverage angle
of about 180° (depending on
the mounting height – a height
of 2.50 m is ideal) (Fig. D).
Make sure the motion detector
9
is not illuminated at night
by street lighting. This can influ-
ence its functioning.
During mounting, proceed as
described below:
Unscrew locking screws
2
by
using a screw driver (cross type)
to detach the mounting bracket
6
from the spotlight
1
.
Hold the mounting bracket
6
so that it is horizontal (possibly
with a spirit level) against the
wall and mark the fastening
holes.
Now drill the fastening holes
(Ø 6 mm) and push the wall
plugs
5
into the drill holes
(Fig. A).
Secure the mounting bracket
6
onto the wall using the mounting
screws
4
provided and check
the tight fit.
Open the connection box
7
by using a cross type screw
driver to loosen the fixing
screws
15
(Fig. B).
