26 GB/IE
Connect as described below:
Remove the protective foil from
the double-sided adhesive tape
(on the back of LED strip)
10
at the ends of the component
pieces of the LED strip
3
be-
ing connected.
Firmly press the end of one
LED
strip
3
onto the contact sp
ikes
of the connection cable
2
so that this pierces the strip
conductor of the LED strip
3
from below (use suitable aid
would be good because the
process requires relative
force).
Note: Ensure that you align
the +GRB markings on the
connection cable
2
with the
+GRB marking of LED strip
3
.
Press a plastic clip
1
onto the
newly-made connection from
above.
Note: The plastic clips
1
must engage to secure the
connection.
Proceed in the same manner
for forming a contact on the
other end of the connection
cable
2
.
Note: The connection cable
2
can move in every direc-
tion, unlike the LED strip
3
.
The product
contains sensitive solder joints.
Do not lead the LED strip
3
around corners or kink. This
could lead to damage of the
solder joints and malfunction
of the LED strip
3
.
Start-up
Switching the
product on / off
using the IR remote
control
Note: The infrared receiver
7
is
located on the LED controller
6
.
Always aim the IR remote control
8
directly at the infrared receiver
7
for best reception. The range of the
IR remote control
8
is approx.
6–8 m.
Note: Remove the insulating strips
from the battery compartment be-
fore using the IR remote control
8
for the first time.
Ensure that there are no ob-
stacles between the sender
and the receiver.
