25 GB/IE
Mounting (see Fig. A)
Note: Clean the surface well
onto which you wish to mount the
product. The surface must be
clean,
free from grease and dry. Other-
wise the stickiness of the double-
sided adhesive tape (for LED
controller)
5
or the double-sided
adhesive tape (on the back of
LED strip)
10
might be limited.
R
emove the protective film fr
om
the adhesive on the back of
the LED strip
3
and attach
the LED strip
3
at the desired
point.
Connect the LED controller
6
to the LED strip
3
.
Note: Ensure when connect-
ing the LED controller
6
with
the LED strip
3
that you
align the +GRB markings on
the LED controller
6
with the
+GRB marking of LED strip
3
.
Attach the LED controller
6
using the attached double-
sided adhesive tape (for LED
controller)
5
.
Please ensure that the power
adaptor
4
is always acces-
sible.
Insert the power adaptor
4
into the socket before you
turn on the product.
Connecting the 2 LED strips:
Note: A maximum of two 5 m
LED strips
3
can be connected
and operated with one LED con-
troller
6
and one power adap-
tor
4
. Otherwise there is the risk
of overloading the components
and fire. Simply connect the head
of secondary light strip to the tail
of first light strips.
Note: Ensure when connecting
the ends of the LED strip
3
that
y
ou align the +GRB markings on
the ends of the strips with each
other.
Shorten the LED strip
(see Fig. B):
You are able to individually shorten
the LED strip
3
. It can be cut with
scissors at the marked position,
as shown in Fig. B. The cut pieces
can be connected together as
shown in the diagram.
