Je bekijkt pagina 17 van 117
the instructions and diagrams in this manual, as well
as with the light itself, before you install it.
□ Before installation ensure that the circuit, to which
the light will be connected, is not energised. To do
so, remove the fuse or switch off the circuit breaker
in the fuse box (0 position).
□ Use the 2-pole voltage tester to verify the de-ener
gised status.
● Start-up
● Mounting the light
□ Remove the screws
4
visible at the side of the
connection housing
5
and remove the mounting
angle
2
from the back.
□ Use the slotted holes in the mounting bracket
2
intended for the screws to mark the bores.
□ Now drill the fixing holes (diameter approx. 6 mm,
depth approx. 40 mm). Be careful not to damage
the supply line.
□ Insert the dowels into the bores.
□
Fasten the mounting bracket
2
with the provided
screws
3
.
□ Feed both the L and N cables through the protective
tubes
8
.
□ Now connect the connection cable of the light to the
mains connection cable (external)
7
using the
terminal block
6
.
Note: Be sure to correctly connect each of
the individual wires of the mains connection
cable (external): black or brown live wire = L
symbol, blue neutral wire = N symbol.
Connect the protective conductor (green-
yellow) to the marked ground terminal
.
inside the connection housing
5
.
□ Now use the screws
4
to screw the light to the
mounting bracket
2
.
□ Replace the fuse or switch on the circuit breaker (I
setting) inside the fuse box.
Your light is now ready to use.
●
Maintenance and cleaning
WARNING! RISK OF ELECTRIC SHOCK!
Disconnect the light from the mains circuit before
cleaning. To do so, remove the fuse or switch off the
circuit breaker in the fuse box (0 position).
WARNING! RISK OF ELECTRIC SHOCK!
For electrical safety, never clean the light with water or
other liquids, or immerse it in water.
CAUTION! DANGER OF BURNS DUE TO
HOT SURFACES!
Allow the light to cool completely.
■
Do not use solvents, benzene or similar substances.
They could damage the light.
□ Only use a dry, lint-free cloth for cleaning.
□
Replace the fuse or switch on the circuit breaker (I
setting) inside the fuse box.
● Disposal
The packaging is made entirely of recy
clable materials, which you may dispose of
at local recycling facilities.
Observe the marking of the packaging
materials for waste separation, which are
marked with abbreviations (a) and numbers
(b) with following meaning: 1–7: plastics /
20–22: paper and fibreboard / 80–98:
composite materials.
The product and packaging materials are
recyclable, dispose of it separately for
better waste treatment. The Triman logo is
valid in France only.
To help protect the environment, please
dispose of the product properly when it has
reached the end of its useful life and not in
the household waste. Information on collec
tion points and their opening hours can be
obtained from your local authority.
GB/IE 17
Prior to installation / Start-up / Maintenance and cleaning / Disposal
