INSTALLATIONOIL GUARDIAN

™

To wire the Oil Guardian, proceed as follows:

When the optional light tower must be installed, include the

light tower power cable in the bundle of cables. For further

mounting instructions of the light tower see Light Tower.

1. Feed the cables through the appropriate cable glands.

2. Route the cables to the front of the Oil Guardian through the cable

trunks on the bottom of the unit.

3. Connect the cables in the control box in accordance with the sticker

inside the door.

4. Install the cable glands.

5. Mount the right side panel.

6. Mount an appropriate plug to the mains cord.

7. Connect the Oil Guardian to the input power.

The test/reset button (See Figure A21, Item L) is used to check that all

LEDs function properly and that all motors are running. This test takes

5 seconds.

Keep away from all moving parts inside the unit to prevent

serious personal injury.

Testing

To test the unit, proceed as follows:

1. Open the door of the Oil Guardian.

2. Press the test/reset button.

3. Check LEDs and that all three motors are functioning.

The direction of rotation of all three motors must be checked. For

this purpose, they are provided with an arrow on the housing indi-

cating the correct direction.

4. Check the direction of rotation of all three motors.

5. If necessary: invert the connection of the phases.

Light Tower (optional)

An external light tower can be installed as an additional warning

device. It must be clearly visible from a distance.

To install the light tower, proceed as follows:

1. Remove input power.

2. Install the light tower at an appropriate position.

3. Route the cable through the front of the Oil Guardian to the inside

the unit.

4. Connect the cable in the control box in accordance with the sticker

on the inside of the door.

5. Install the cable gland.

Function and Settings

The amount of limestone depends on the size of the connected filter

system. This is arranged by a time controlled screw conveyor. The

applicable time settings must be programmed in the PLC which is

located in the control box inside the door.

Depending on the type of Oil Guardian you are using, the unit is

equipped with either a Siemens or Allen-Bradley PLC.

To program the amount of limestone, proceed as follows:

For steps 1-3, see Figure 22.

1. Check the type of PLC.

2. In case of a PLC type Siemens, proceed with PLC: Siemens instruc-

tions.

3. In case of a PLC type Allen-Bradley Micro830, proceed with PLC:

Allen-Bradley Micro830 instructions.

WARNING

ATTENTION

FIGURE 22

FIGURE 21
