Section 2 Installation
Document #: LIN_EOGO_IOM_24APERION_4605890_Rev1 - 01/24 17
For Floor Installation
1. When placing the Oven on the floor, use the Long Leg
Kit with Casters on the Bottom Unit. If Stacking Option is
being used, ensure the Long Leg Kits are on the Bottom
unit. The Bottom Unit will have the Stack Top Cover
Option installed.
Non-Stacking
Cover With No
Holes On Top
Stack Cover Taller
With Holes
Long Legs With
Casters
2. Remove Front Door, Upper and Lower Fingers and
Conveyor Assembly from the Top and Bottom Units. The
removal of these items will make the installation of the
Top Unit on the Bottom Unit easier to place.
NOTE: Only single and double stack configurations are
permitted to use the long leg kit.
3. With the Bottom Unit on blocks, connect the Long Leg
Kit to the bottom of the Bottom Unit in 4 places.
Long Legs Kit
4-Places
Stack Cover Taller
With Holes
Long Legs With
Casters
4. When using the Long Legs, the Unit must be restrained.
Adjust and trim the Adjustable Restraining Cable Kit to
secure the Unit to the wall or floor. Ensure that the Cable
is short enough to limit the Oven Unit movement.
Restraining
Hole
