8.3.1 Moving the flexible ice compartment
divider
Fig. 95 Example illustration of the ice compartment divider
► Move the ice compartment divider to the desired
position.
8.3.2 Removing the flexible ice compart‐
ment divider
Make sure that the following requirements are fulfilled:
❑
Ice cube drawer is removed. (see8.1 Drawers)
Fig.96
► Lift the rear part of the ice compartment divider.
Fig.96(1)
► Remove the ice compartment divider upwards.
Fig.96(2)
8.3.3 Putting in the flexible ice compart‐
ment divider
Make sure that the following requirements are fulfilled:
❑
Ice cube drawer is removed. (see8.1 Drawers)
Fig.97
► Insert the front part of the ice compartment divider.
Fig.97(1)
► Lower the rear part of the ice compartment divider
to the drawer bottom. Fig.97(2)
9 Maintenance
9.1 Air exchange through the FreshAir
activated charcoal filter
Wine is constantly developing according to its ambient
conditions, so air quality is essential for preservation.
The FreshAir activated charcoal filter guarantees
optimal air quality.
❑
Change the activated charcoal filter every 6 months.
❑
Dispose of the activated charcoal filter with regular
household waste.
Note
FreshAir activated charcoal filters can be purchased
from the Liebherr Service Center. The address for your
respective country can be found on the back of the
instructions.
9.1.1 Replacing the FreshAir activated char‐
coal filter
Must be carried out multiple times depending on the
equipment.
Fig.98
► Remove the panel.
Fig.99
► Pull the drawer out.
Maintenance
* Depending on model and options 27
