8 Equipment
8.1 Drawers
You can remove the drawers for cleaning.
The way to remove/insert the drawers varies
depending on the pull-out system. Your appliance can
contain a variety of pull-out systems.
Note
Insufficient ventilation results in an increase in energy
consumption and reduction of the refrigerating
performance.
► Leave the bottom drawer in appliance!
► Never obstruct the vents on the interior rear wall!
8.1.1 Drawer on telescopic rails
The drawer runs on full-extension rails (telescopic
rails). There are full-extension telescopic rails and tele‐
scopic rails with partial pull-out. Drawers which are full
extension can be pulled out fully from the appliance.
Drawers with partial pull-out cannot be pulled out fully
from the appliance. The system in your appliance
depends on the type of appliance.
Partial pull-out freezing compartment
Note
If the magnet on the top drawer in the freezing
compartment is damaged or removed, the door sensor
will malfunction.
► Do not damage or remove the magnet.
Removing drawer
Fig.92
If the drawer is in the top freezer:
► Pull out drawer as far as it will go.
► Lift up the front of the drawer.
► Remove the drawer from the front.
► Slide rails in.
-or-
Fig. 93
If the drawer is in the middle of the freezing
compartment:
► Pull out drawer halfway.
►
Lift the back of the drawer from the bottom.
► Remove the drawer from the front.
► Slide rails in.
Inserting drawer
Fig. 94
► Slide rails in.
► Guide drawer around the stoppers Fig. 94(1).
► Place drawer on rails.
► Slide in drawer to the back.
8.2 IceMaker
The IceMaker is used exclusively for the production of
ice cubes in household quantities.
Make sure that the following conditions are fulfilled
-
IceMaker is cleaned. (see9 Maintenance)
-
IceMaker drawer is cleaned.
-
IceMaker drawer is fully inserted.
8.2.1 Producing ice cubes
The production capacity depends on the freezer
temperature The lower the temperature, the more ice
cubes can be produced in a certain period
Once IceMaker is switched on for the first time, it can
take up to 24 hours to produce the first ice cubes.
► Activate the IceMaker function.
► Making many ice cubes: Activate the MaxIce func‐
tion.
► To make a large quantity of ice cubes: Move or
remove the separators in the IceMaker drawer.
► Distribute ice cubes evenly in the drawer to increase
its capacity.
► Close the drawer: The IceMaker starts making ice
again.
Note
When a certain level is reached in the IceMaker drawer,
it stops making ice cubes. The IceMaker does not fill
the drawer to the very top.
8.3 Flexible ice compartment divider
The IceMaker’s ice cube drawer has a flexible ice
compartment divider. This allows you to store larger
quantities of ice cubes or additional food items as
needed. You can move or remove the ice compartment
divider.
Equipment
26 * Depending on model and options
