Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Internal rubber
Remove the 2242 solid-state drive (SSD)
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 27
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove one screw and then remove the SSD by pulling it away from the slot.
Figure 8. Remove the SSD
Screw specifications
Number of screws
M1.6 x L1.7 1
Step 3. Remove one screw and then remove the SSD bracket from the SSD.
Figure 9. Remove the SSD bracket
Screw specifications
Number of screws
M1.6 x L1.7 1
Step 4. Remove the SSD mylar.
30
Hardware Maintenance Manual
