Figure 10. Remove the SSD mylar
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
2242 Solid-state drive (SSD)
Solid-state drive (SSD) mylar
Solid-state drive (SSD) bracket
Remove the 2280 solid-state drive (SSD)
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 27
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove one screw and then remove the SSD by pulling it away from the slot.
Figure 11. Remove the SSD
Screw specifications
Number of screws
M1.6 x L1.7 1
Step 3. Remove the SSD mylar.
Figure 12. Remove the SSD mylar
Chapter 4. Removing a FRU or CRU 31
