Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove three screws and then remove the battery pack.
Figure 6. Remove the battery pack
Screw specifications Number of screws
M2 x L3.5 3
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Battery pack
Remove the internal rubber
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 27
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove the internal rubber.
Figure 7. Remove the internal rubber
Chapter 4. Removing a FRU or CRU 29
