Notes:

• Depending on the computer model, your computer might look different from the illustration above.

• The Lenovo factory recovery USB key

a is used to restore the Microsoft Windows operating system. It

might not come with the computer, and a user might order it from

https://pcsupport.lenovo.com/

lenovorecovery

, though additional shipping and handling fees might apply.

Miscellaneous parts

Table 6. Miscellaneous part

FRU descriptions

Self-service

CRU

Optional-service

CRU

Screw kit

• For ThinkPad X1 Carbon Gen 12:

– M1.2 x L1.7 (10)

– M1.2 x L2.1 (4)

– M1.6 x L2.6 (12)

– M2 x L2.0 Fine pitch (19)

– M2 x L2.0 Big hat (6)

– M2 x L2.8 (10)

– M2 x L4.0 (2)

– M2.5 x L4.0 (8)

– Spec

• For ThinkPad X1 2-in-1 Gen 9:

– M1.2 x L1.7 (10)

– M1.2 x L2.1 (4)

– M1.6 x L2.6 (12)

– M2 x L2.0 Fine pitch (19)

– M2 x L2.0 Big hat (6)

– M2 x L2.8 (10)

– M2.5 x L4.0 (12)

– Spec

No No

Mechanical miscellaneous kit

• Spec

No No

Label kit:

• Label

• Spec

No No

Connector and cable guide

This topic provides information to help Lenovo authorized service technicians identify connectors and cables

for replacement purpose. To view each FRU and the exploded illustration of the computer, see “Major FRUs

and CRUs” on page 46.

Note: Depending on your computer model, some connectors or cables might not be available.

48

ThinkPad X1 Carbon Gen 12 and ThinkPad X1 2-in-1 Gen 9 Hardware Maintenance Manual
