Table 5. Major FRUs and CRUs

No. FRU description

Self-service

CRU

Optional-service

CRU

1

LCD unit

Note: LCD unit is a single FRU.

No No

2

Keyboard bezel assembly No No

3

Trackpad* No No

4

Haptic Touchpad* No No

5

Coin cell battery No No

6

Thermal fan assembly No No

7

Speaker assembly

No No

8

System board with SSD thermal pad No No

9

Wireless-WAN antenna assembly* No No

10

Base cover assembly Yes No

11

WWAN antenna cable guide rubber* No No

12

Thermal pad for Wireless-WAN card* No No

13

Wireless-WAN card* Yes No

14

Wireless-WAN card bracket* Yes No

15

M.2 solid-state drive Yes No

16

M.2 solid-state drive bracket Yes No

17

Built-in battery

Note: The battery comes with captured screws.

No No

18

Touchpad, fingerprint reader, P sensor and NFC cable (for

models with NFC)

No No

19

Touchpad, fingerprint reader and P sensor cable (for models

without NFC)

No No

20

Touchpad Spill mylar

No No

21

NFC module sponge*

No No

22

NFC module*

No No

23

Nano-SIM-card tray*

Yes No

24

USB bracket

No No

25

Fan cable guide No No

26

Lenovo Slim Pen (for ThinkPad X1 2-in-1 Gen 9 only) Yes No

a

Lenovo factory recovery USB key*

No No

b

Miscellaneous parts kits (see “Miscellaneous parts” on page 48)

No No

c

Power cord* Yes No

d

ac power adapter* Yes No

* for selected models

Chapter 6. Locations 47
