Step 2. Install the LCD bezel with webcam privacy shutter in reverse order.
Note: Ensure that all the latches are attached firmly.
LCD hinges
Follow the instructions to replace the LCD hinges.
For access, remove these FRUs in order:
• “Base cover assembly” on page 72
• “LCD unit” on page 102
• “LCD bezel with webcam privacy shutter” on page 106
Step 1. Remove the LCD hinges as shown below.
Table 14. For models with plastic cover
Step Screw (quantity) Color Torque
1
M2.5 × L4.5 mm, flat-head, nylon-coated (6) Silver
0.294 Nm
(3.0 kgf-cm)
Chapter 8. Removing or replacing a FRU 107
