Remove the DIMM shielding and the memory module
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 29
Step 1. Disconnect the battery pack cable from the system board (1) and peel back the mylar (2).
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Figure 12. Disconnect the battery pack cable and peel back the mylar
Step 2. Remove the DIMM shielding (3).
Figure 13. Remove the DIMM shielding
Step 3. Open the latches (4) and remove the memory module (5).
Chapter 4. Removing a FRU or CRU 35
