RAK112B_ENG / 2023-06-27
13 / 40
7.3. EVF200 mounting on ground mounting frame
Installation accessories
Ground mounting frame EVTL28.00 1 pcs
Ground mounting box EVTL32.00 / EVTL34.00 1 pcs
Make sure that the materials used for the concrete foundation and the installation procedures follow local
building regulations and safety standards.
• Plan the installation depth so that the top surface of the ground mounting frame is ush with the
nal ground surface. Take into consideration the possible paving materials.
• Dig a trench for cable conduits and an excavation pit (depth approximately 490 mm) for the concrete
foundation. The pit oor should be compacted and level.
• Put the ground mounting frame into the pit.
• Put cable and possible drain pipes in place.
• Pour concrete over the frame and pipes.
• Let the concrete cure. Make sure that the surface stays level during the process.
Installation steps
1. Remove the upper nuts and washers from the top of the ground mounting frame bolts.
2. Put the mounting box on the mounting frame.
3. Adjust the nuts on the mounting frame bolts so that the top surface of the mounting box is hori-
zontal.
4. EVTL32.00: Pull electrical cables through the ground mounting box cable gland(s) approx. 400 mm
measured from the upper end of the mounting box.
EVTL34.00: Pull electrical cables through the ground mounting box cable gland(s) and further
through the mounting box cable hole approx. 400 mm measured from the upper end of the mount-
ing box.
5. Tighten the cable gland. Close the unused cable entries with cable gland plugs.
6. Open the maintenance door of the charging station.
7. Remove the nuts and the washers from the ground mounting box.
8. Lift the charging station on the mounting box. Pull the electrical cables through the cable hole.
9. Attach the charging station in place with the washers and the nuts you removed from the ground
mounting box.
10. EVTL32.00: Remove the supply cable sheath at the length of max. 200 mm.
EVTL34.00: Remove the supply cable sheath beginning from the cable gland exit.
11. Cut the supply cable conductors to applicable lengths. The earth conductor must be long enough,
so that if a fault occurs it is the last one that comes loose.
12. Strip the supply cable conductors 25 mm.
13. Connect the supply cable wires to the supply terminal blocks.
14. Make sure that the PE is connected to the charging station.
15. Switch on F0, F1, F2 (if present) and QF1.
16. Close the maintenance door.
